A typical Android app tends to be composed of many layers, modules or structures such as Fragments, Activities, Presenters, and Services. Effective communication between these components can become difficult if they are tightly coupled together.
In the lower level of your app architecture, such as the database, when an action happens, you might want to send data to a higher level such as the view. To do this, you might want to create a listener interface, async tasks or callbacks. All of these will work, but they have some major drawbacks:
- direct or tight coupling
- registering and unregistering multiple dependencies individually
- repetition of code
- difficulty in testing
- increased risk of bugs
Using publish/subscribe or message bus architecture prevents all the potential problems highlighted above. It is a very good way to implement effective communications between components in an application without any of them needing to be aware of the others immediately. Using publish/subscribe in Android, any app component can publish events which it will hand over to the bus, and the relevant consumers can consume or subscribe to them.
To use greenrobot EventBus, you need to first add it to in the app module build.gradle file, include compile 'org.greenrobot:eventbus:3.0.0', and then sync your project afterwards.
An Event Subscriber
A subscriber simply subscribes to an event by registering in the event bus and can also unregister that event. To be a subscriber, you have to do three main things:
1. Register the subscriber in the event bus with register(). This informs the event bus that you want to begin receiving events. In an activity, this is in the onStart() method, while in a fragment put this in the onAttact(Activity activity) method.
@Override
public void onStart() {
super.onStart();
EventBus.getDefault().register(this);
}
2. Unregister the subscriber, which means tell the event bus to stop sending me events. In an activity, this is in the onStop() method, while in a fragment put this in the onDetach() method.
@Override
public void onStop() {
super.onStop();
EventBus.getDefault().unregister(this);
}
3. Implement the onEvent() to indicate the type of event you want to receive and action to take when you receive the event. Notice the @Subscribe annotation at the top of this method. In this case, we want to subscribe to a normal event and not a sticky one—I'll explain the difference later.
@Subscribe
public void onEvent(MessageEvent event) {
Toast.makeText(this, "Hey, my message" + event.getMessage(), Toast.LENGTH_SHORT).show();.
}
Defining Event Messages
The events in greenrobot EventBus are just objects that you define. You can have different event classes if you want. They do not inherit any base class or interface—they're just POJO (Plain Old Java Objects).
public class MessageEvent {
public String mMessage;
public MessageEvent(String message) {
mMessage = message;
}
public String getMessage() {
return mMessage;
}
}
Post Event and Post Sticky Event
The main difference between post event and post sticky event is the caching mechanism employed inside the event bus. When someone posts a sticky event, this event is stored in a cache. When a new activity or fragment subscribes to the event bus, it gets the latest sticky event from the cache instead of waiting for it to be fired again to the event bus—so this event stays in the cache even after a subscriber has gotten it.
Sticky events are posted with the postSticky(MessageEvent) method, and non-sticky events with the post(MessageEvent) method.
EventBus.getDefault().postSticky(new MessageEvent("Hey event subscriber!"));
EventBus.getDefault().post(new MessageEvent("Hey event subscriber!"));
For a regular, non-sticky event, if there no subscriber is found, the event will be thrown away. A sticky event will be cached, though, in case a subscriber comes along later.
So when do you decide to use post sticky event? You can do this if you are tracking down the user's location, or for simple caching of data, tracking battery levels, etc.
EventBus.getDefault().postSticky(new LocationReceivedEvent(6.4531, 3.3958))
Subscribe to Post Sticky Event
// UI updates must run on MainThread
@Subscribe(sticky = true, threadMode = ThreadMode.MAIN)
public void onEvent(MessageEvent event) {
textField.setText(event.getMessage());
}
To subscribe to a sticky event, you include sticky = true inside the @Subscribe annotation. This indicates that we want to receive a sticky event of type MessageEvent from the cache.
Removing Sticky Events
LocationReceivedEvent locationReceivedStickyEvent = EventBus.getDefault().getStickyEvent(LocationReceived.class);
if(stickyEvent != null) {
EventBus.getDefault().removeStickyEvent(locationReceivedStickyEvent);
}
removeStickyEvent(Event) removes a sticky event from the cache, and removeAllStickyEvents() will remove all sticky events.
EventBus Thread Modes
There are four thread modes available for subscribers to choose from: posting, main, background, and async.
Posting
@Subscribe(threadMode = ThreadMode.POSTING)
This is the default. Subscribers will be called in the same thread as the thread where the event is posted. Including ThreadMode.POSTING in your @Subscribe annotation is optional.
Main
@Subscribe(threadMode = ThreadMode.MAIN)
In this thread mode, subscribers will receive events in the main UI thread, no matter where the event was posted. This is the thread mode to use if you want to update UI elements as a result of the event.
Background
@Subscribe(threadMode = ThreadMode.BACKGROUND)
In this thread mode, subscribers will receive events in the same thread where they are posted, just like for ThreadMode.POSTING. The difference is that if the event is posted in the main thread, then subscribers will instead get them on a background thread. This makes sure that event handling doesn't block the app's UI. Still, don't run an operation that will take a long time on this thread.
Async
@Subscribe(threadMode = ThreadMode.ASYNC)
In this thread mode, subscribers will always receive events independently from the current thread and main thread. This enables the subscribers to run on a separate thread. This is useful for long-running operations such as network operations.
Subscriber Priorities
If you want to change the order in which subscribers get events, then you need to specify their priority levels during registration. Subscribers with a higher priority get the event before subscribers with a lower priority. This only affects subscribers in the same thread mode. Note that the default priority is 0.
@Subscribe(priority = 1);
public void onEvent(MessageEvent event) {
textField.setText(event.getMessage());
}
Cancelling Events
If you want to stop an event from being delivered to other subscribers, call the cancelEventDelivery(Object event) method inside the subscriber's event handling method.
@Subscribe
public void onEvent(MessageEvent event){
EventBus.getDefault().cancelEventDelivery(event);
}
Conclusion
In this tutorial, you learned about:
- greenrobot EventBus and how it can improve your Android app
- the difference between regular and sticky events
- the different thread modes available and when to use each one
- subscriber priorities
- cancelling an event to stop receiving events
To learn more about greenrobot EventBus, I suggest you visit the official documentation.
Another library you can use to implement an event bus is RxAndroid. Check out our article on RxAndroid here on Envato Tuts+, or try some of our other Android courses or tutorials.
