Android UI Workshop: Build an Interactive Quiz App

Get a hands-on crash course in building an effective and attractive UI for your Android app, and design an interactive quiz app along the way!

Looking for a Shortcut?

In this tutorial, we'll build a quiz app from the ground app, but if you're looking for a quicker solution, check out Envato Market's Quiz App Template for Android. It's a well-designed template that you can customize as you wish to create your own quiz app from a solid foundation.

If you'd prefer to build it from scratch by yourself, read on for the instructions.

Step 0: Getting Started

For the Android app developer, user interface (UI) is key. Your app may boast cutting-edge functionality, but if it’s wrapped in an unappealing UI it’s unlikely that users will stick around long enough to discover just how great your app really is.

This tutorial provides a hand’s on, crash course in building an effective UI, using the example of a simple quiz app. The app poses a question and presents the user with four possible answers, implemented as ImageButtons. ‘Correct’ and ‘Incorrect’ messages are displayed via a popup, and the user can see at a glance which version of the app they’re running.

As you build the app, we’ll cover the following:

RelativeLayout
Designing for multiple screens
Adding and leveraging image resources
String resources
App accessibility
Creating stylish text
Custom XML Styles
Making buttons ‘tappable’
Toast notifications

Start by creating an Android project called ‘AndroidGame’ and a new Activity (we’ll stick with the default ‘MainActivity’ filename.) Delete the ‘Hello World’ TextView that Eclipse generates automatically, along with any default parent view that has been added.

EDITOR'S NOTE: This tutorial is based on the Vectortuts+ artwork created in the tutorial "How to Create a Pub Chalkboard UI in Adobe Illustrator" by Sharon Milne.

Step 1: Define a RelativeLayout

A RelativeLayout is a flexible layout that allows you to organize UI elements in relation to one another, making it particularly useful for developers who need fine-grained control over the exact positioning of their UI components.

Create a basic RelativeLayout view group to hold all your UI elements:


<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent" >

  </RelativeLayout>

Step 2: Designing for Multiple Screens: Background Image

As an open source operating system, Android crops up on all sorts of devices, and is the OS of choice for many different manufacturers - it’s no longer even restricted to smartphones! This presents both exciting opportunities and headache-inducing challenges for Android developers. When developing your UI, keep in mind that your app needs to display correctly across as many devices as possible. While designing for multiple screens is too broad a topic for this tutorial, as a starting point you should provide alternate versions of every image used in your app. These alternate images should be optimized for screens with different pixel densities. When your app launches, Android will automatically load the correct image based on the device’s display characteristics.

Open the ‘res’ folder and you will see four drawable folders that Eclipse generates by default:

drawable-ldpi
drawable-mdpi
drawable-hdpi
drawable-xhdpi

These folders target screens with different pixel densities, following a 3:4:6:8 scaling ratio (for example, if drawable-ldpi contains an image of 36 x 36 pixels, then drawable-mdpi should contain an image of 48 x 48 pixels, and so on).

Create four versions of your background image based on this ratio, and drag each version into the appropriate folder.

Add the background image to RelativeLayout using the ‘android:background’ attribute, referring to the image resource as you would any drawable object:


<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:background="@drawable/background" >

</RelativeLayout>

Boot up the Android Emulator and take a look at your work so far.

Step 3: Creating ImageButtons

The first step of creating an ImageButton is to add the required images to your project. Again, because you want your device to display correctly across a range of screens, you should provide four versions of each image. We’ll start with the ‘2003’ button, so drag and drop the four versions of your ‘2003’ image into the corresponding folders.

ImageButtons are created using the ‘ImageButton’ tag followed by the usual height/width attributes, and some RelativeLayout-specific alignment attributes.

Create your first ImageButton and tweak the alignment until you’re happy with how it’s positioned. In this example, I’m using the following:


<ImageButton
        android:id="@+id/imageButton1"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_centerHorizontal="true"
        android:layout_centerVertical="true">

But your ImageButton is missing the most important part: an image! Refer to this image as a drawable resource, but this time using the ‘android:src’ property:


<ImageButton
        android:id="@+id/imageButton1"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_centerHorizontal="true"
        android:layout_centerVertical="true"
        android:src="@drawable/button2003" />

Check how this appears in the emulator.

Repeat this process for the other four buttons. This is a good opportunity to experiment with the various RelativeLayout attributes (the Android docs are a great source of additional information on the different layouts.)

As you fine-tune your layout, you may find it useful to keep the emulator open, switching between it, the graphical layout editor and your XML.

Here’s the code I’m using:


<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
	xmlns:tools="http://schemas.android.com/tools"
	android:layout_width="match_parent"
	android:layout_height="match_parent"
	android:background="@drawable/background" >

	<ImageButton
    	android:id="@+id/imageButton1"
    	android:layout_width="wrap_content"
    	android:layout_height="wrap_content"
    	android:layout_centerHorizontal="true"
    	android:layout_centerVertical="true"
    	android:src="@drawable/button2003" />

	<ImageButton
    	android:id="@+id/imageButton2"
    	android:layout_width="wrap_content"
    	android:layout_height="wrap_content"
    	android:layout_below="@+id/imageButton1"
    	android:layout_centerHorizontal="true"
    	android:src="@drawable/button2004" />

	<ImageButton
    	android:id="@+id/imageButton3"
    	android:layout_width="wrap_content"
    	android:layout_height="wrap_content"
    	android:layout_below="@+id/imageButton2"
    	android:layout_centerHorizontal="true"
    	android:src="@drawable/button2005" />

	<ImageButton
    	android:id="@+id/imageButton4"
    	android:layout_width="wrap_content"
    	android:layout_height="wrap_content"
    	android:layout_below="@+id/imageButton3"
    	android:layout_centerHorizontal="true"
    	android:src="@drawable/button2006" />

</RelativeLayout>

The buttons may be displaying correctly in the emulator, but Eclipse is throwing multiple "Missing contentDescription attribute on image" errors. What’s this all about?

Step 4: Making Your App Accessible

The ContentDescrition attribute makes applications more accessible to users who cannot easily consume graphical content, by providing an alternate text description. This description can be used by screen readers and similar accessibility tools.

The first step is to define some new string resources. Strings are defined in the res/layout/strings.xml file, so open it and switch to the strings.xml tab if necessary.

String resources are created with the following syntax:


<string name="name">Text to display</string>

Define a string for the ContentDescription of each ImageButton:


<string name="button2003">Answer 2003</string>
<string name="button2004">Answer 2004</string>
<string name="button2005">Answer 2005</string>
<string name="button2006">Answer 2006</string>

Return to your activity_main.xml file and add a ContentDescription attribute to each ImageButton, e.g:

 android:contentDescription="@string/button2003"/>

Step 5: Creating Stylish Text

In reality, it’s unlikely you’ll cease developing an app at Version 1.0, as you cook up new content and release fixes for any pesky bugs that users discover. Therefore, it’s handy if people can tell at a glance what version of your app they’re running. The easiest way to do this is with a TextView.

Open the strings.xml file and define the current version number as a string:

 <string name="Version">Version 1.0</string>

You can quickly create a TextView that calls "@string/Version" but Android’s default text style isn’t particularly appealing. Thankfully, TextView has a range of attributes that can give boring old text some pizazz. You can read more about all the available attributes at the Android docs, but in this tutorial we’ll use the following:

android:textColor - sets the colour of your text. It can either be defined as a string resource, or as a colour value (for more information on values, see the Android Docs: Colour section.)
android:textSize - sets the text size, which can be given either as px (pixels) sp (scaled pixels) dp (density-independent pixels) in (inches) or mm (millimeters)
android:textStyle - either italic or bold.

Create your TextView, add some style attributes, and then reference the “Version” string:


<TextView
    android:id="@+id/textView1"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:layout_alignParentBottom="true"
    android:layout_alignParentLeft="true"
    android:layout_marginLeft="26dp"
    android:paddingBottom="5dp"
    android:text="@string/Version"
    android:textColor="#f7f9f6"
    android:textSize="13dp"
    android:textStyle="italic" />

This works, but if you’re planning to re-use this set of attributes elsewhere then you should define it as a custom "Style." A style is a time-saving collection of properties (in this case font colour, font size, and the italic style) that specifies the appearance of a view, or even an entire application.

You’ll often hear ‘styles’ and ‘themes’ mentioned in a similar context. Essentially, the only difference between a style and a theme is their scope: ‘styles’ that are applied to activities become ‘themes.'

To define a custom style:

Open the res/values/styles.xml file, ensure it has opening and closing ‘resource’ tags, and give your style a unique name:

 <resources>
     <style name="VersionFont">
     </style>
</resources>

Define all the attributes that belong to this style:
```
 <item name="android:textSize">13dp</item>
```

For this tutorial, we’ll define the following custom style:


<resources>
  <style name="VersionFont">
      <item name="android:textColor">#f7f9f6</item>
      <item name="android:textSize">13dp</item>
      <item name="android:textStyle">italic</item>
  </style>
</resources>

Applying this custom style to your TextView is easy, simply replace all the attributes defined by the VersionFont style, with: style="@style/VersionFont".

e.g:


<TextView
   android:id="@+id/textView1"
   android:layout_width="wrap_content"
   android:layout_height="wrap_content"
   android:layout_alignParentBottom="true"
   android:layout_alignParentLeft="true"
   android:layout_marginLeft="26dp"
   android:paddingBottom="5dp"
   android:text="@string/Version"
   style="@style/VersionFont" />

This custom style isn’t defined in the Android namespace, which is why we don’t need to include an "android:" reference.

Both of these methods are valid ways of styling text, but keep in mind that a custom style can speed up the coding process if you’re going to re-use the same collection of attributes across your application.

Step 6: Making Your App Interactive

Your UI may be finished, but there’s one final step: letting the user know whether they’ve selected the correct answer. The easiest way to make buttons ‘tappable’ is by implementing the android:onClick property for each button.

We’ll start by adding it to the first button:


<ImageButton
       android:id="@+id/imageButton1"
       android:layout_width="wrap_content"
       android:layout_height="wrap_content"
       android:layout_centerHorizontal="true"
       android:layout_centerVertical="true"
       android:src="@drawable/button2003"
       android:contentDescription="@string/button2003"
       android:onClick="onClick2003"   />

The name of the onClick method must correspond to a public method in the MainActivity.Java file, so add the following to your Activity:

   public void onClick2003 (View view)

Now specify the behaviour that "onClick2003" triggers. A straightforward way of telling the user they’ve got the question wrong, is with a toast notification:


public void onClick2003 (View view)
{
    Toast.makeText(this, "Wrong! Try again", Toast.LENGTH_SHORT).show();
}

Run this updated code in the emulator and get clicking to check your toast is firing properly.

Success!

Add onClick to the other three buttons and create corresponding public methods in your Activity, with appropriate messages attached. Once you’ve finished, boot up the emulator and have a click around to check everything’s working okay.

Conclusion

Over the course of this tutorial you’ve learned the essentials of Android UI design and created a simple, but effective UI that has some working functionality to boot! Try applying some of these techniques to your own Android projects, to ensure your UI doesn’t let your app down.
